procedure TForm1.FormCreate(Sender: TObject);
begin
  doublebuffered := true;
end;

procedure TForm1.QUADER14Change(Sender: TObject);
begin
  TrackBar1.Position := TQUADER(Sender).Position;
end;

procedure BeiStartUndLauf(Sender: TQUADER);
begin
  Form1.TrackBar1.Position := Sender.Position;
end;

procedure TForm1.FormCreate(Sender: TObject);
begin
  doublebuffered := true;
end;

procedure TForm1.FormActivate(Sender: TObject);
begin
  BeiStartUndLauf(QUADER14);
end;

procedure TForm1.QUADER14Change(Sender: TObject);
begin
  if visible then
    BeiStartUndLauf(TQUADER(Sender));
end;

//------------------------------------------------------

uses Jpeg;

var
  br: integer;

procedure TForm1.FormCreate(Sender: TObject);
begin
  doublebuffered := true;
  Timer1.Interval := 0;
end;

// Bild laden und starten
procedure TForm1.Button1Click(Sender: TObject);
var
  b: TBitmap;
  j: TJpegImage;
begin
  b := TBitmap.Create;
  j := TJpegImage.Create;
  j.LoadFromFile('D:\Bilder\Test.jpg');
  b.Assign(j);
  j.Free;
  br := b.Width div 2;
  QUADER14.Width := br;
  QUADER14.Picture := b;
  b.Free;
  Timer1.Interval := 50;
end;

// stoppen und Bild löschen
procedure TForm1.Button2Click(Sender: TObject);
begin
  Timer1.Interval := 0;
  QUADER14.Picture := nil;
end;

procedure TForm1.Timer1Timer(Sender: TObject);
begin
  with QUADER14 do
  begin
    PictOffsetHorz := PictOffsetHorz - 2;
    if PictOffsetHorz <= -br then
      PictOffsetHorz := 0;
  end;
end;

unit QUADER;

interface

uses
  Windows,
  Classes,
  SysUtils,
  Graphics,
  Controls,
  StdCtrls;

type
  TQUADER = class(TCustomLabel)
  private
    Fx, Fwmx, Fhmy, FLang, FStelle, Foffsh, Foffsv, Fmerk, Fdiff: Integer;
    FHorz, Fcov, Ftrans, Fhd, Fpfo, Fpfix, Fauto, Fb2, Fflip: boolean;
    Fc, Fclr, Fr, Fft, Ffr, Fr2, Ffl: TColor;
    Fpt1, Fpt2: array [0 .. 4] of TPoint;
    FBild, Fbm, Fhlp: TBitmap;
    Fmin, Fmax, FPos: int64;
    FEvent: TNotifyEvent;
    Fd: Word;
  protected
    function korrc(c: TColor): TColor;
    procedure korrdepth(var w: Word);
    procedure setoffsh(i: Integer);
    procedure setoffsv(i: Integer);
    procedure setbild(gr: TBitmap);
    procedure settrans(b: boolean);
    procedure setLine2(c: TColor);
    procedure setHorz(b: boolean);
    procedure setauto(b: boolean);
    procedure setflip(b: boolean);
    procedure setpfix(b: boolean);
    procedure setCov(b: boolean);
    procedure HVpoly(i: Integer);
    procedure setLine(c: TColor);
    procedure setBack(c: TColor);
    procedure setBart(c: TColor);
    procedure setBarl(c: TColor);
    procedure setBarr(c: TColor);
    procedure setpfo(b: boolean);
    procedure setb2(b: boolean);
    procedure sethd(b: boolean);
    procedure b90(Uhr: boolean);
    procedure setmin(i: int64);
    procedure setmax(i: int64);
    procedure setpos(i: int64);
    procedure setfd(w: Word);
    procedure setbereich;
    procedure korrOffset;
    procedure zeichnen;
    procedure poskorr;
    procedure rech;
    procedure korr;
  public
    constructor Create(AOwner: TComponent); override;
    destructor Destroy; override;
    procedure Resize; override;
    procedure Paint; override;
  published
    property CoverTransparent: boolean read Ftrans write settrans;
    property PictOffsetHorz: Integer read Foffsh write setoffsh;
    property PictOffsetVert: Integer read Foffsv write setoffsv;
    property OnChange: TNotifyEvent read FEvent write FEvent;
    property Horizontal: boolean read FHorz write setHorz;
    property BorderColor2: TColor read Fr2 write setLine2;
    property PictFaceOnly: boolean read Fpfo write setpfo;
    property HideAtMinimum: boolean read Fhd write sethd;
    property PictFixed: boolean read Fpfix write setpfix;
    property DepthAuto: boolean read Fauto write setauto;
    property PictFlip: boolean read Fflip write setflip;
    property BorderColor1: TColor read Fr write setLine;
    property Picture: TBitmap read FBild write setbild;
    property CoverColor: TColor read Fc write setBack;
    property BarColor1: TColor read Fft write setBart;
    property BarColor2: TColor read Ffl write setBarl;
    property BarColor3: TColor read Ffr write setBarr;
    property BorderBack: boolean read Fb2 write setb2;
    property Cover: boolean read Fcov write setCov;
    property Position: int64 read FPos write setpos;
    property Min: int64 read Fmin write setmin;
    property Max: int64 read Fmax write setmax;
    property Depth: Word read Fd write setfd;
    property ParentShowHint;
    property OnMouseMove;
    property OnMousedown;
    property OnDblClick;
    property OnMouseUp;
    property ShowHint;
    Property Visible;
    property Enabled;
    property OnClick;
    property Hint;
  end;

procedure Register;

implementation

const
  mn = 8;

procedure Register;
begin
  RegisterComponents('DBR', [TQUADER]);
end;

constructor TQUADER.Create(AOwner: TComponent);
begin
  inherited Create(AOwner);
  autosize := false;
  Ftrans := false;
  FHorz := false;
  Fpfix := true;
  Fauto := true;
  Fcov := true;
  Fhd := true;
  Fb2 := true;
  color := 1;
  Fclr := color;
  Fmerk := maxint;
  Transparent := true;
  Fbm := TBitmap.Create;
  FBild := TBitmap.Create;
  Fbm.Transparent := true;
  Fbm.PixelFormat := pf24bit;
  Fbm.TransparentColor := Fclr;
  Fd := 10;
  Fmax := 100;
  width := 27;
  height := 132;
  Fc := $E0E0E0;
  Fr := $707070;
  Fr2 := $C5C5C5;
  Fft := $FF0000;
  Ffl := $B80000;
  Ffr := $800000;
end;

destructor TQUADER.Destroy;
begin
  FBild.Free;
  Fbm.Free;
  inherited Destroy;
end;

Procedure TQUADER.rech;
begin
  if Fauto then
  begin
    Fd := round(sqrt(height * width) / 6);
    korrdepth(Fd);
  end;
  if FHorz then
    Fx := width - Fd
  else
    Fx := Fd;
  Fwmx := pred(width - Fx);
  Fhmy := pred(height - Fd);
end;

function TQUADER.korrc(c: TColor): TColor;
begin
  if odd(c) then
    result := pred(c)
  else
    result := succ(c);
end;

procedure TQUADER.korr;
begin
  if Fr = Fclr then
    Fr := korrc(Fr);
  if Fr = Fc then
  begin
    if Fr and $100 = $100 then
      Fr := Fr - $100
    else
      Fr := Fr + $100
  end;
end;

Procedure TQUADER.zeichnen;
var
  x, w: Integer;
  procedure hg;
  begin
    with Fbm.Canvas do
      if Ftrans then
        brush.color := Fclr
      else
        brush.color := Fc;
  end;

begin
  korr;
  Fbm.width := width;
  Fbm.height := height;
  with Fbm.Canvas do
  begin
    brush.color := Fclr;
    fillrect(cliprect);
    if FHorz then
    begin
      if (not Fhd) or (FPos > Fmin) then
      begin
        Pen.color := Ffr;
        brush.color := Ffr;
        polygon(Fpt1);
        Pen.color := Fft;
        brush.color := Fft;
        polygon(Fpt2);
        Pen.color := Ffl;
        brush.color := Ffl;
        rectangle(0, Fd, FLang + 1, height);
        if not FBild.empty then
        begin
          if FBild.width + Foffsh > FLang then
            w := FLang - Foffsh + 1
          else
            w := FBild.width;
          if not Fpfo then
            for x := Foffsv to Fd - 1 do
              copyrect(rect(Fd - x, x, w + Foffsh + Fd - x, x + 1),
                FBild.Canvas, rect(-Foffsh, x - Foffsv, w,
                  x + 1 - Foffsv));
          copyrect(rect(Foffsh, Fd, Foffsh + w, FBild.height + Foffsv),
            FBild.Canvas, rect(0, Fd - Foffsv, w, FBild.height));
        end;
      end
      else if Fcov and Fb2 then
      begin
        hg;
        Pen.color := Fr2;
        polygon(Fpt1);
      end;
      if Fcov then
      begin
        Pen.color := Fr;
        brush.Style := bsclear;
        rectangle(0, Fd, Fx, height);
        hg;
        moveto(0, Fd);
        lineto(Fd, 0);
        lineto(width - 1, 0);
        lineto(width - 1, Fhmy);
        lineto(Fx - 1, height - 1);
        if FLang < Fx - 2 then
        begin
          Floodfill(width - 2, 2, pixels[width - 2, 2], fsSurface);
          Pen.color := brush.color;
          moveto(Fx, height - 3);
          lineto(width - 2, Fhmy);
        end;
        if FLang < Fx - 3 then
          Floodfill(Fx - 2, height - 2, pixels[Fx - 2, height - 2], fsSurface);
        Pen.color := Fr;
        moveto(Fx - 1, Fd);
        lineto(width - 1, 0);
        if Fb2 then
        begin
          Pen.color := Fr2;
          moveto(Fpt1[2].x + 1, Fpt1[2].y);
          if FLang + Fwmx < Fx - 1 then
          begin
            lineto(Fx - 1, Fpt1[2].y);
            moveto(Fx, Fpt1[2].y);
          end;
          lineto(width - 1, Fpt1[2].y);
        end;
      end;
    end
    else
    begin
      if (not Fhd) or (FPos > Fmin) then
      begin
        Pen.color := Fft;
        brush.color := Fft;
        polygon(Fpt1);
        Pen.color := Ffl;
        brush.color := Ffl;
        polygon(Fpt2);
        Pen.color := Ffr;
        brush.color := Ffr;
        rectangle(Fx, height - FLang - 1, width, height);
        if not FBild.empty then
        begin
          if FBild.height > FLang + Foffsv then
            w := FLang + 1
          else
            w := FBild.height - Foffsv;
          if not Fpfo then
            for x := 0 to Fd - 1 do
            begin
              copyrect(rect(x, height - w - Fd + x, x + 1, height - Fd + x),
                FBild.Canvas, rect(x - Foffsh, FBild.height - w - Foffsv,
                  x + 1 - Foffsh, FBild.height - Foffsv));
            end;
          copyrect(rect(Fd, height - FLang - 1, FBild.width + Foffsh,
              height + Foffsv), FBild.Canvas,
            rect(Fd - Foffsh, FBild.height - FLang - Foffsv - 1, FBild.width,
              FBild.height));
        end;
      end
      else if Fcov and Fb2 then
      begin
        hg;
        Pen.color := Fr2;
        polygon(Fpt1);
      end;
      if Fcov then
      begin
        Pen.color := Fr;
        brush.Style := bsclear;
        rectangle(Fx, Fd, width, height);
        hg;
        moveto(Fx + 1, height);
        lineto(0, Fhmy);
        lineto(0, 0);
        lineto(Fwmx, 0);
        lineto(width - 1, Fd);
        if FLang < Fhmy - 1 then
        begin
          Floodfill(1, 1, pixels[1, 1], fsSurface);
          Pen.color := brush.color;
          moveto(Fwmx, 1);
          lineto(width - 2, Fd);
        end;
        if FLang < Fhmy - 2 then
          Floodfill(width - 2, Fd + 1, pixels[width - 2, Fd + 1], fsSurface);
        Pen.color := Fr;
        moveto(0, 0);
        lineto(Fx, Fd);
        if Fb2 then
        begin
          Pen.color := Fr2;
          moveto(Fpt1[2].x, Fpt1[2].y - 1);
          if FLang + Fd < Fhmy then
          begin
            lineto(Fpt1[2].x, Fd);
            moveto(Fpt1[2].x, Fd - 1);
          end;
          lineto(Fpt1[2].x, 0);
        end;
      end;
    end;
  end;
  Canvas.draw(0, 0, Fbm);
end;

Procedure TQUADER.Paint;
begin
  setbereich;
  zeichnen;
end;

Procedure TQUADER.setHorz(b: boolean);
var
  i: Integer;
begin
  if b <> FHorz then
  begin
    FHorz := b;
    if not(csLoading in componentstate) then
    begin
      i := height;
      height := width;
      width := i;
      if not FBild.empty then
      begin
        if Fflip then
        begin
          if b then
          begin
            i := Foffsv;
            Foffsv := Foffsh;
            Foffsh := -i;
          end
          else
          begin
            i := Foffsh;
            Foffsh := Foffsv;
            Foffsv := -i;
          end;
          b90(b);
        end
        else
          poskorr;
      end;
      repaint;
      if assigned(FEvent) then
        FEvent(self);
    end
    else
      invalidate;
  end;
end;

Procedure TQUADER.setLine(c: TColor);
begin
  c := ColorToRgb(c);
  if c <> Fr then
  begin
    Fr := c;
    invalidate;
  end;
end;

Procedure TQUADER.setLine2(c: TColor);
begin
  c := ColorToRgb(c);
  if c <> Fr2 then
  begin
    Fr2 := c;
    invalidate;
  end;
end;

Procedure TQUADER.setBack(c: TColor);
begin
  c := ColorToRgb(c);
  if c <> Fc then
  begin
    if c = Fclr then
      c := korrc(c);
    Fc := c;
    Ftrans := false;
    invalidate;
  end;
end;

Procedure TQUADER.setBart(c: TColor);
begin
  c := ColorToRgb(c);
  if c <> Fft then
  begin
    if c = Fclr then
      c := korrc(c);
    Fft := c;
    invalidate;
  end;
end;

Procedure TQUADER.setBarl(c: TColor);
begin
  c := ColorToRgb(c);
  if c <> Ffl then
  begin
    if c = Fclr then
      c := korrc(c);
    Ffl := c;
    invalidate;
  end;
end;

Procedure TQUADER.setBarr(c: TColor);
begin
  c := ColorToRgb(c);
  if c <> Ffr then
  begin
    if c = Fclr then
      c := korrc(c);
    Ffr := c;
    invalidate;
  end;
end;

Procedure TQUADER.setCov(b: boolean);
begin
  if b <> Fcov then
  begin
    Fcov := b;
    invalidate;
  end;
end;

Procedure TQUADER.settrans(b: boolean);
begin
  if b <> Ftrans then
  begin
    Ftrans := b;
    invalidate;
  end;
end;

procedure TQUADER.sethd(b: boolean);
begin
  if b <> Fhd then
  begin
    Fhd := b;
    invalidate;
  end;
end;

procedure TQUADER.setauto(b: boolean);
begin
  if b <> Fauto then
  begin
    Fauto := b;
    rech;
    invalidate;
  end;
end;

procedure TQUADER.setpfo(b: boolean);
begin
  if b <> Fpfo then
  begin
    Fpfo := b;
    if not FBild.empty then
    begin
      if FHorz then
      begin
        if b then
          Foffsv := Foffsv + Fd
        else
          Foffsv := Foffsv - Fd;
      end
      else
      begin
        if b then
          Foffsh := Foffsh + Fd
        else
          Foffsh := Foffsh - Fd;
      end;
    end;
    invalidate;
  end;
end;

procedure TQUADER.setpfix(b: boolean);
begin
  if b <> Fpfix then
  begin
    Fpfix := b;
    Fmerk := maxint;
    korrOffset;
    invalidate;
  end;
end;

procedure TQUADER.setb2(b: boolean);
begin
  if b <> Fb2 then
  begin
    Fb2 := b;
    invalidate;
  end;
end;

procedure TQUADER.setflip(b: boolean);
begin
  if b <> Fflip then
  begin
    Fflip := b;
    invalidate;
  end;
end;

procedure TQUADER.setmax(i: int64);
begin
  if i <> Fmax then
  begin
    if i <= Fmin then
      i := Fmin + 1;
    if FPos > i then
      FPos := i;
    Fmax := i;
    invalidate;
  end;
end;

procedure TQUADER.setmin(i: int64);
begin
  if i <> Fmin then
  begin
    if i >= Fmax then
      i := Fmax - 1;
    if FPos < i then
      FPos := i;
    Fmin := i;
    invalidate;
  end;
end;

procedure TQUADER.korrOffset;
begin
  if not Fpfix then
  begin
    if FHorz then
      Foffsh := Foffsh + Fdiff
    else
      Foffsv := Foffsv - Fdiff;
    Fmerk := FLang;
  end;
end;

procedure TQUADER.setpos(i: int64);
begin
  if i < Fmin then
    i := Fmin;
  if i > Fmax then
    i := Fmax;
  if not Enabled or (i = FPos) then
    exit;
  FPos := i;
  setbereich;
  korrOffset;
  repaint;
  if assigned(FEvent) then
    FEvent(self);
end;

procedure TQUADER.setbereich;
var
  i: Integer;
  Ber: int64;
begin
  rech;
  Ber := Fmax - Fmin;
  FStelle := FPos - Fmin;
  if FHorz then
    i := Fx - 2
  else
    i := height - Fd - 2;
  FLang := round(FStelle * i / Ber);
  if Fmerk < maxint then
    Fdiff := FLang - Fmerk;
  HVpoly(FLang);
end;

procedure TQUADER.HVpoly(i: Integer);
var
  hm1: Integer;
begin
  hm1 := pred(height);
  if FHorz then
  begin
    Fpt1[0] := point(i, Fd);
    Fpt1[1] := point(i + Fd, 0);
    Fpt1[2] := point(i + Fd, Fhmy);
    Fpt1[3] := point(i, hm1);
    Fpt2[0] := point(i + Fd, 0);
    Fpt2[1] := point(Fd, 0);
    Fpt2[2] := point(0, Fd);
    Fpt2[3] := point(i, Fd);
  end
  else
  begin
    Fpt1[0] := point(Fx, hm1 - i);
    Fpt1[1] := point(0, Fhmy - i);
    Fpt1[2] := point(Fwmx, Fhmy - i);
    Fpt1[3] := point(width - 1, hm1 - i);
    Fpt2[0] := point(0, Fhmy - i);
    Fpt2[1] := point(0, Fhmy);
    Fpt2[2] := point(Fx, hm1);
    Fpt2[3] := point(Fx, hm1 - i);
  end;
  Fpt1[4] := Fpt1[0];
  Fpt2[4] := Fpt2[0];
end;

procedure TQUADER.poskorr;
begin
  if FHorz then
  begin
    if Fpfix then
      Foffsh := 0
    else
      Foffsh := succ(FLang - FBild.width);
    Foffsv := ord(Fpfo) * Fd;
  end
  else
  begin
    if Fpfix then
      Foffsv := 0
    else
      Foffsv := pred(FBild.height - FLang);
    Foffsh := ord(Fpfo) * Fd;
  end;
  korrOffset;
end;

procedure TQUADER.setbild(gr: TBitmap);
var
  b1, b2: boolean;
  x, y, w: Integer;
  p: PByteArray;
begin
  b1 := FBild.empty;
  b2 := (gr = nil) or gr.empty;
  FBild.Assign(gr);
  if not b2 then
  begin
    poskorr;
    FBild.PixelFormat := pf24bit;
    w := FBild.width * 3;
    for y := 0 to FBild.height - 1 do
    begin
      p := FBild.ScanLine[y];
      x := 0;
      while x < w do
      begin
        if (p[x] = 0) and (p[x + 1] = 0) then
        begin
          if p[x + 2] = 1 then
            p[x + 2] := 0;
        end;
        inc(x, 3);
      end;
    end;
  end;
  repaint;
  if (b1 <> b2) or not b2 then
    if assigned(FEvent) then
      FEvent(self);
end;

procedure TQUADER.b90(Uhr: boolean);
var
  a: array of array of array [0 .. 2] of byte;
  x, y, h, w, w3: Word;
  p: PByteArray;
  i: byte;
  procedure rechnen(b, c: Word);
  var
    j: byte;
  begin
    for j := 0 to 2 do
      p[x + j] := a[b][c][j];
  end;

begin
  setlength(a, FBild.height);
  h := pred(FBild.height);
  for x := 0 to h do
    setlength(a[x], FBild.width);
  w3 := FBild.width * 3;
  for y := 0 to h do
  begin
    p := FBild.ScanLine[y];
    x := 0;
    while x < w3 do
    begin
      for i := 0 to 2 do
        a[h - y][x div 3][i] := p[x + i];
      inc(x, 3);
    end;
  end;
  x := FBild.height;
  FBild.height := FBild.width;
  FBild.width := x;
  h := pred(FBild.height);
  w3 := FBild.width * 3;
  w := pred(FBild.width);
  for y := 0 to h do
  begin
    p := FBild.ScanLine[y];
    x := 0;
    while x < w3 do
    begin
      if Uhr then
        rechnen(x div 3, y)
      else
        rechnen(w - x div 3, h - y);
      inc(x, 3);
    end;
  end;
  a := nil;
end;

procedure TQUADER.setoffsh(i: Integer);
begin
  if i <> Foffsh then
  begin
    Foffsh := i;
    invalidate;
  end;
end;

procedure TQUADER.setoffsv(i: Integer);
begin
  if i <> Foffsv then
  begin
    Foffsv := i;
    invalidate;
  end;
end;

procedure TQUADER.setfd(w: Word);
begin
  korrdepth(w);
  if w <> Fd then
  begin
    Fd := w;
    Fauto := false;
    invalidate;
  end;
end;

procedure TQUADER.korrdepth(var w: Word);
const
  m = 3;
var
  x, y: Integer;
begin
  if width < height then
    x := width
  else
    x := height;
  y := round(x / 1.5);
  if w < m then
    w := m
  else if w > y then
    w := y;
end;

Procedure TQUADER.Resize;
begin
  if width < mn then
    width := mn;
  if height < mn then
    height := mn;
  korrdepth(Fd);
end;

end.
